Produkt Details
SKU
404201
Name
JUMO differential pressure monitor
Description
The type 4 ADS product acquires the negative pressure, overpressure, or differential pressure of air, smoke, and exhaust gases in ventilation, air-conditioning, and filter systems. It is suitable to switch a current circuit ON, OFF or change it over, when the actual value changes in relation to the setpoint value.
Short Description
For air, smoke, and exhaust gases
Price
€279.23
Availability
In Stock
Images
State
LIVE
cf-data
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
title
Icon
icon-certificate
Description
TÜV test as pressure monitoring
Icon
icon-shield
Description
Protection type: IP54 IEC 529 (EN 60529)
Icon
icon-wranch
Description
Additional air-conditioning set for mounting
title
Technical data
datasheet
https://www.jumo.net/attachments/JUMO/attachmentdownload?id=4208
Medium temperature
-15 to +60 °C
Setting ranges
0.0004 to 1.5 bar differential pressure
Switching point accuracy
± 15 %
Operating pressure
0 to 0.5 bar
Protection type
IP54
Contact type
1-pole switch as toggle fine silver (Ag)
Cable entry
Pg 11
Electrical connection
Screw connection up to 2.5 mm² conductor cross section
